RECO RM-BV4 Micro DP User Manual

Documentation RM-BV4 Micro DP
RDN 10000662 3 24.01.2014
1 Safety instructions
Improper installation of the RM-BV 4 Micro DP or associated equipment may cause the failure of the
device, serious or even fatal injuries. In addition to general safety rules for equipment in industrial
electrical installations, pay particular attention to the following points:
- The RM-BV 4 Micro DP must only be installed by qualified persons according to the provisions of the
standards IEC 364 and DIN VDE 0105 for electrical equipment.
- All applicable laws, conditions, rules and regulations governing the installation of electrical equipment
must be observed.
- Equipment with protection rating IP00 without covers must only be configured by authorised expert
staff when disconnected and whilst observing the local safety and accident prevention rules.
- The RM-BV 4 Micro DP is only allowed to be operated in its specified operating range.
Switch off the supply voltage before replacing the RM-BV 4 Micro DP
or components
connected to it. Failure to do so may cause equipment damage.
2 Device description
The RM-BV 4 Micro DP is used to control 24VDC solenoid valves on filtering separators with pressure
pulse cleaning. Once connected to the power supply, the filter control works automatically without further
operating.

RECO RM-BV4 Micro DP Specifications

General

Brand	RECO
Model	RM-BV4 Micro DP
Category	Controller
Language	English
