RECO RM-BV4 Micro DP User Manual

Documentation RM-BV4 Micro DP
RDN 10000662 7 24.01.2014
4.1 Connection of the differential pressure measuring hoses
5 Settings
5.1 Function in "as delivered" condition
Using the set control times for pulse time and pause time, all connected solenoid valves are controlled
one after the other starting with a cleaning pulse. Once the last valve has been operated, the control
circulation is continued with the first valve. This happens until the supply voltage is turned off. Once the
supply voltage has been turned on again, a restart occurs as described above.
 Use the hoses with 4 mm internal diameter
and 6mm outside diameter.

Connect the connector marked with 3 stripes
(black screw cap) with
the raw gas side and
the other connector (blue screw cap) with the
clean gas side of the filter.
