10.11. WG250/O Support Arm Extension Kit
10.12. WG250/N Profiled Leather Honing Wheel
The extension arm mounts on the support arm and allow the user to sharpen
and hone without having to reposition the support arm and reset the angle
of the jig.
A Lock knob
B Extension arm holder
C Extension arm
The profiled leather honing wheel is used to hone the insides of profiles on
tool such as woodturning roughing gouges.
With the support arm mounted in the side position, apply the tool to the
wheel as shown in Fig 10.12.1. Always hone with the wheel moving away
from the blade to avoid damage to the leather.
Using the Extension Arm
Place the extension arm holder onto the support arm ensuring the threaded
hole is facing the opposite direction of the support arm and secure in place
by tightening the lock knobs.
Mount the support arm in the side position.
Screw the extension arm into the holder as shown in Fig 10.11.1.
B
A
C
Fig 10.11.1
Fig 10.12.1
