Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 11/ 56
Open position If the door has reached the planned opening width, pull the
brake in all operating modes. This is also valid in case of re-
duced opening width.
▪ If the door stops e.g. due to safety signals or because of a
collision, the brake is not activated.
Closed/Open position In all operating modes pull the brake when the door is closed
or open (see above).
Closed, One-Way/Locked
In operating modes
One-Way
and
Locked
pull the brake when
the door is closed.
Closed, Locked Only pull the brake in operating mode
Locked
when the door is
closed.
Motor Definition of the motor type (ATE) being used.
▪ If no motor type is yet configured (e.g. according to factory
settings), some motor types can be automatically identified
and configured by the controller software.
▪ The selection of motor types is limited according to STM
Without X No motor is connected or motor type unknown.
ATE 20 ATE STA 20 (GR63x55), automatic identification
ATE 21 ATE STA 21 (GR63x25), automatic identification
ATE 19 small ATE STA 19 (GR63x25), no automatic identification
ATE 19 big ATE 19 (GR63x55), no automatic identification
ATE 16 normal ATE 16, no automatic identification
ATE 16 heavy ATE 16, (1:15) no automatic identification
ATE 17 ATE 17 (GR63x25), no automatic identification
ATE 20 folding door ATE 20 with special pulley for,
folding door type
automatic
identification in case of a folding door.
ATE 16 folding door ATE 16 with special pulley for
folding door
no automatic identi-
fication
ATE 16 30V ATE 16 30V for industrial application, no automatic identifica-
tion.
ATE 20/200 ATE 20/200 (GR63x55) with special pulley for 200 mm installa-
tion height, no automatic identification.
