Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 38/ 56
→ APS Open-position 35 Opening width in the case of APS control.
▪ Normally, a floor bolt or a second lock is mounted as a
protection against burglary attempts. The opening width
must be set so that the door stops shortly before impact.
▪ With correct
Parameter → Entrance system → Door leaf
a
value of 40 corresponds to an opening width of approx. 18
→ AUX10_IN Configurable input signal for FEM1
Connector J1, terminals 64 & 65
Floating, optically disconnected 24V input
→ Disabled X
→ S_AUS Interlock control inactive.
▪
Both doors open at the same time when activated from one
side. SIS is active and stops the affected door.
→ APS lock Locking bolt surveillance for pharmacy control.
0V/open = bolt extended
24V = bolt retracted, door can open
▪ An extended locking bolt is displayed on the BDE-D with
the text
APS Riegel
(bolt).
→ AUX11_IN Configurable input signal for FEM1
Connector J1, terminals 66 and 67 (only FEM1)
Floating, optically disconnected 24V input
→ Disabled X
→ SEA Input signal for synchronisation of an interlock.
▪ The signal
Block activation
prevents any door opening as
long as the interlock is in use from the other door. An acti-
vation signal is buffered until the interlock chamber is re-
other door. Only then does the door open.
→ APS opening Opening signal for pharmacy control.
▪ Triggers door opening provided that locking bolt surveil-
lance has given approval. As long as the contact is activat-
ed (24V on input) the door remains open.
→ AUX12_IN Configurable input signal for FEM1.
Connector J1, terminals 68 and 69 (only FEM1)
Floating, optically disconnected 24V input
→ Disabled X
→ SFS_IN Input "interlock sequential control".
▪ Appropriate for interlocks and "draught lobbies" without
triggering sensors within the interlock chamber.
▪ The signal must be linked with the output signal SFS_OUT
of the other door. The latter transmits the triggering signal
