Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 39/ 56
→ AUX13_IN Configurable input signal for FEM1
Connector J1, terminals 70 and 71 (only FEM1)
Floating, optically disconnected 24V input
→ Disabled X
→ AUX10_OUT … AUX1D_OUT 14 configurable output signals for FEM1.
Connector J2, floating change over contact 30 volt DC / 1 A
Normally closed (NC) or normally open (NO) contact (selection
via jumper position --> basic position = NO contact).
→ Inactive X
→ Alarm output This output signal indicates severe breakdowns.
Relay passive = breakdown
Relay active = no breakdown
→ Locked This output signal shows whether the door is locked.
Relay passive = door not locked
Relay active = door closed and locked
→ Closed This output signal shows whether the door is closed.
Relay passive = door not closed
Relay active = door closed
▪ The outp
ut may switch with a slight delay, i.e. when closing
only after the pressing phase and, when opening by hand,
not before the door has opened up to approx. 10 mm.
→ Open This output signal shows whether the door is open.
Relay passive = door not open
Relay active = door has opened up to opening width
▪ The output may connect with a slight delay, i.e. when
opening not before the end stop has been recognised and,
when closing by hand, not before the door has been pulled
closed approx. 30 mm.
→ AKI This output signal shows that a triggering signal on the inner
side of the door is active.
▪
The output connects independently of the current operating
mode.
→ AKA
This output signal indicates that a triggering signal on the outer
side of the door is active.
▪
The output connects independently of the current operating
mode.
