→ AKI / AKA This output signal indicates that a triggering signal on the inner
or outer side of the door is active.
▪ The output connects independently of the current
operating
mode.
→ SSK This output signal shows that an SSK signal is active.
▪
The output connects independently of the current operating
mode
→ SAMP Signal for connecting an optical and/or acoustic indicator in an
interlock control.
▪ This signal shows that an opening command is registered,
but cannot yet be carried out, because the interlock is oc-
cupied from the opposite door.
→ SAA Output signal for synchronisation of an interlock.
▪ With the signal Block triggering the other door is notified
that the interlock is currently occupied.
→ SFS_OUT Output interlock sequential control.
▪ Appropriate for interlocks and draught lobbies without trig-
gering sensors within the interlock chamber.
▪ The signal must be linked with the input signal SFS_IN of
the other door. Thus, the triggering signal is transmitted to
the first door.
→ APS signal light For connecting a signal light in a pharmacy control.
▪ The signal shows that the pharmacy function is activated
and the door can be opened with the APS opening signal.
▪ It is recommended to use an opening switch with integrat-
ed lighting and to connect the output to the lighting.
→ Automatic OM The relay is active as long as Automatic operating mode is
selected - also in the event of reduced opening width.
→ One-Way OM The relay is active as long as One-Way operating mode is
selected - also in the event of reduced opening width.
→ Locked OM The relay is active as long as Locked or Locked manual oper-
ating mode is selected.
▪
The signal remains active even during an SSK opening.
→ Continuously open OM The relay is active as long as Continuously open operating
mode is selected - also in the event of reduced opening width.
→ Manual OM The relay is active as long as Manual operating mode is se-
lected.
→ Off OM The relay is active as long as Off operating mode is selected.
