Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 42/ 56
INPUT/OUTPUT
→ AKA_IN This parameter is used to configure for which operating modes
the triggering signals on the outside of the door are active.
→ AKA X A closed door can only be opened with an AKA signal in oper-
ating mode
Automatic
(standard behaviour). In operating
modes
One-Way
and
Locked
the door is reversed and/or
maintained open by the AKA signal.
→ Inactive with One-Way
and Locked
AKA signals are only active in operating mode
Automatic
.
→ Disabled AKA signals are basically inactive.
▪ This setting allows e.g. to only use the presence surveil-
lance and to ignore the triggering function of a combined
→ SÖK/NSK Configures the behaviour of the control unit for input signal
SÖK/NSK.
→ Function Function of signal SÖK/NSK.
→ Disabled Signal is not analysed.
→ SÖK Safety opening
▪ The signal opens the door in all operating modes to the
maximum opening width with highest priority, even if it is
locked.
▪ The door opens at reduced speed, and safety signals are
not taken into account during the opening movement.
▪ Collision surveillance is active, however, no reversing
→ NSK Manual mode,
SSK enabled
Emergency closing with subsequent
Manual operation
.
▪ The signal closes the door in all operating modes with
highest priority. Then the door changes to
Manual mode
. If
the door is slid open by hand, it closes again after approx.
10 seconds.
▪ The door can be opened at any time with an SSK signal.
▪ The door closes at reduced speed, and safety signals are
not taken into account during the closing movement. Colli-
sion surveillance is active; however, no reversing takes
place.
A locked door is unlocked, but remains closed.
