red lion PAX2D User Manual

27
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
40051 40091 Counter B Scale Factor (Hi word)
1 999999 100000 Read/Write 1 = 0.00001 (decimal point fixed)
40052 40092 Counter B Scale Factor (Lo word)
40053 40093 Counter C Scale Factor (Hi word)
1 999999 100000 Read/Write 1 = 0.00001 (decimal point fixed)
40054 40094 Counter C Scale Factor (Lo word)
Counter Count Load Values
40055 40095 Counter A Count Load (Hi word)
-199999 999999 500 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40056 40096 Counter A Count Load (Lo word)
40057 40097 Counter B Count Load (Hi word)
-199999 999999 500 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40058 40098 Counter B Count Load (Lo word)
40059 40099 Counter C Count Load (Hi word)
-199999 999999 500 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40060 40100 Counter C Count Load (Lo word)
INPUT PARAMETERS SEE INPUT MODULE FOR PARAMETER DESCRIPTIONS
Counter A
40121 Counter A Operating Mode 0 13 0 Read/Write
0 = None
7 = Quad x2
1 = Count
8 = Quad x4
2 = Count U/D
9 = Dual Quad x1
3 = Dual Count U/D
10 = Dual Quad x2
4 = Add/Add
11 = Count x2
5 = Add/Sub
12 = Count U/D x2
6 = Quad x1
13 = Dual Count U/D x2
40122 Counter A Decimal Point 0 5 0 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000, 5 = 0.00000
40123 Counter A Scale Multiplier 0 3 0 Read/Write 0 = 1, 1 = 0.1, 2 = 0.01, 3 = 10
40124 Counter A Reset Action 0 1 0 Read/Write 0 = Reset to Zero, 1 = Reset to Counter A Count Load Value
40125 Counter A Reset at Power-up 0 1 0 Read/Write 0 = No, 1 = Yes
40126 Input A Active Count Edge (Logic) 0 1 0 Read/Write 0 = Falling Edge, 1 = Rising Edge
40127 Prescaler Output Enable 0 1 0 Read/Write 0 = No, 1 = Yes
40128 Prescaler Output Scale Value 1 10000 10000 Read/Write 1 = 0.0001
Counter B
40131 Counter B Operating Mode 0 7 0 Read/Write
0 = None 3 = Dual Count U/D 6 = Count x2
1 = Batch 4 = Dual Quad x1 7 = Dual Count U/D x2
2 = Count 5 = Dual Quad x2
40132 Counter B Decimal Point 0 5 0 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000, 5 = 0.00000
40133 Counter B Scale Multiplier 0 3 0 Read/Write 0 = 1, 1 = 0.1, 2 = 0.01, 3 = 10
40134 Counter B Reset Action 0 1 0 Read/Write 0 = Reset to Zero, 1 = Reset to Counter B Count Load Value
40135 Counter B Reset at Power-up 0 1 0 Read/Write 0 = No, 1 = Yes
40136 Input B Active Count Edge (Logic) 0 1 0 Read/Write 0 = Falling Edge, 1 = Rising Edge
40137 Counter B Batch Count Source 0 15 0 Read/Write
Bit State: 0 = No, 1 = Yes
Bit 3 = S4, Bit 2 = S3, Bit 1 = S2, Bit 0 = S1
Counter C
40141 Counter C Operating Mode 0 6 0 Read/Write
0 = None
3 = Add (A+B) 6 = Slave
1 = Counter A 4 = Subtract (A-B)
2 = Counter B 5 = Batch
40142 Counter C Decimal Point 0 5 0 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000, 5 = 0.00000
40143 Counter C Scale Multiplier 0 3 0 Read/Write 0 = 1, 1 = 0.1, 2 = 0.01, 3 = 10
40144 Counter C Reset Action 0 1 0 Read/Write 0 = Reset to Zero, 1 = Reset to Counter C Count Load Value
40145 Counter C Reset at Power-up 0 1 0 Read/Write 0 = No, 1 = Yes
40146 Counter C Batch Count Source 0 15 0 Read/Write
Bit State: 0 = No, 1 = Yes
Bit 3 = S4, Bit 2 = S3, Bit 1 = S2, Bit 0 = S1
Rate A
40151 Rate A Enable 0 1 0 Read/Write 0 = No, 1 = Yes
40152 Rate A Decimal Point 0 4 0 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000
40153 Rate A Low Cut-Out Value (Hi word)
0 999999 0 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40154 Rate A Low Cut-Out Value (Lo word)
40155 Rate A Display Rounding 0 6 0 Read/Write 0 = 1, 1 = 2, 2 = 5, 3 = 10, 4 = 20, 5 = 50, 6 = 100
40156 Rate A Scaling Points 2 10 2 Read/Write Number of Rate A Linearizer Scaling Points
40157 Scaling Pt.1 Display Value (Hi word)
0 999999 0 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40158 Scaling Pt.1 Display Value (Lo word)
40159 Scaling Pt.1 Input Value (Hi word)
0 999999 0 Read/Write 1 = 0.1Hz
40160 Scaling Pt.1 Input Value (Lo word)
40161 Scaling Pt.2 Display Value (Hi word)
0 999999 1000 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40162 Scaling Pt.2 Display Value (Lo word)
40163 Scaling Pt.2 Input Value (Hi word)
0 999999 10000 Read/Write 1 = 0.1Hz
40164 Scaling Pt.2 Input Value (Lo word)
thru Scaling Pts. 3 thru 9 Values … … … Read/Write Registers 40165-40192 hold values for Scaling Points 3 thru 9.
40193 Scaling Pt.10 Display Value (Hi word)
0 999999 0 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40194 Scaling Pt.10 Display Value (Lo word)
40195 Scaling Pt.10 Input Value (Hi word)
0 999999 0 Read/Write 1 = 0.1Hz
40196 Scaling Pt.10 Input Value (Lo word)
