red lion PAX2D User Manual

28
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
Rate B
40201 Rate B Enable 0 1 0 Read/Write 0 = No, 1 = Yes
40202 Rate B Decimal Point 0 4 0 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000
40203 Rate B Low Cut-Out Value (Hi word)
0 999999 0 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40204 Rate B Low Cut-Out Value (Lo word)
40205 Rate B Display Rounding 0 6 0 Read/Write 0 = 1, 1 = 2, 2 = 5, 3 = 10, 4 = 20, 5 = 50, 6 = 100
40206 Rate B Scaling Points 2 10 2 Read/Write Number of Rate B Linearizer Scaling Points
40207 Scaling Pt.1 Display Value (Hi word)
0 999999 0 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40208 Scaling Pt.1 Display Value (Lo word)
40209 Scaling Pt.1 Input Value (Hi word)
0 999999 0 Read/Write 1 = 0.1Hz
40210 Scaling Pt.1 Input Value (Lo word)
40211 Scaling Pt.2 Display Value (Hi word)
0 999999 1000 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40212 Scaling Pt.2 Display Value (Lo word)
40213 Scaling Pt.2 Input Value (Hi word)
0 999999 10000 Read/Write 1 = 0.1Hz
40214 Scaling Pt.2 Input Value (Lo word)
thru Scaling Pts. 3 thru 9 Values … … … Read/Write
Registers 40215-40242 hold values for Scaling Points 3 thru
9.
40243 Scaling Pt.10 Display Value (Hi word)
0 999999 0 Read/Write 1 = 1 in least significant digit (disregard decimal point)
40244 Scaling Pt.10 Display Value (Lo word)
40245 Scaling Pt.10 Input Value (Hi word)
0 999999 0 Read/Write 1 = 0.1Hz
40246 Scaling Pt.10 Input Value (Lo word)
Rate C
40251 Rate C Calculation 0 1 0 Read/Write
0 = None 2 = Difference (A-B) 4 = Pct.of Total (A/A+B)
1 = Sum (A+B) 3 = Ratio (A/B) 5 = Pct.Draw (A-B/B)
40252 Rate C Display Multiplier 0 3 0 Read/Write 0 = 1, 1 = 10, 2 = 100, 3 = 1000
40253 Rate C Decimal Point 0 4 0 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000
Rate Update
40254 Rate Low Update Time 1 9999 10 Read/Write 1 = 0.1 Sec (decimal point fixed)
40255 Rate High Update Time 2 9999 20 Read/Write 2 = 0.2 Sec (decimal point fixed)
Rate Hi/Lo Capture
40256 Max (Hi) Capture Value Assignment 0 2 0 Read/Write 0 = Rate A, 1 = Rate B, 2 = Rate C
40257 Max (Hi) Capture Delay Time 0 9999 10 Read/Write 1 = 0.1 Sec (decimal point fixed)
40258 Min (Lo) Capture Value Assignment 0 2 0 Read/Write 0 = Rate A, 1 = Rate B, 2 = Rate C
40259 Min (Lo) Capture Delay Time 0 9999 10 Read/Write 1 = 0.1 Sec (decimal point fixed)
User Input / Function Keys
40271 User Input Active State 0 1 0 Read/Write 0 = Active Low, 1 = Active High
40272 User Input 1 Action 0 23 0 Read/Write
0 = NO
7 = Color 14 = RSt-L 21 = SPS-L
1 = PLOC
8 = d-LEV 15 = RSt-E 22 = SPS-E
2 = SEL L1
9 = d-Cont 16 = Inhibt 23 = SPHOLd
3 = SEL L2
10 = d-OFF 17 = StorE
4 = RSt L1
11 = LISt 18 = St-rSt
5 = RSt L2
12 = Print 19 = SPr-L
6 = RStL12
13 = Pr-rSt 20 = SPr-E
40273 User Input 1 Assignment 0 31 0 Read/Write
Counter/Hi/Lo Asn (Bit State: 0 = No, 1 = Yes):
Bit 0 = CTA, Bit 1 = CTB, Bit 2 = CTC, Bit 3 = Hi, Bit 4 = Lo
Setpoint Asn: Bit 0 = S1, Bit 1 = S2, Bit 2 = S3, Bit 3 = S4
List Asn: Bit 3 = Units Mnemonics
40274 User Input 2 Action 0 23 0 Read/Write Same as User Input 1 Action
40275 User Input 2 Assignment 0 31 0 Read/Write Same as User Input 1 Assignment
40276 User Input 3 Action 0 23 0 Read/Write Same as User Input 1 Action
40277 User Input 3 Assignment 0 31 0 Read/Write Same as User Input 1 Assignment
40278 User F1 Key Action 0 22 1 Read/Write
0 = NO
6 = Color 12 = Pr-rSt 18 = SPr-L
1 = SEL L1
7 = d-LEV 13 = RSt-L 19 = SPr-E
2 = SEL L2
8 = d-Cont 14 = RSt-E 20 = SPS-L
3 = RSt L1
9 = d-OFF 15 = Inhibt 21 = SPS-E
4 = RSt L2
10 = LISt 16 = StorE 22 = SPHOLd
5 = RSt L12
11 = Print 17 = St-rSt
40279 User F1 Key Assignment 0 31 0 Read/Write Same as User Input 1 Assignment
40280 User F2 Key Action 0 22 0 Read/Write Same as User F1 Key Action
40281 User F2 Key Assignment 0 31 0 Read/Write Same as User Input 1 Assignment
40282 User F1 Second Action 0 22 0 Read/Write Same as User F1 Key Action
40283 User F1 Second Action Assignment 0 31 0 Read/Write Same as User Input 1 Assignment
40284 User F2 Second Action 0 22 0 Read/Write Same as User F1 Key Action
40285 User F2 Second Action Assignment 0 31 0 Read/Write Same as User Input 1 Assignment
