29
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
OUTPUT PARAMETERS SEE OUTPUT MODULE FOR PARAMETER DESCRIPTIONS
Setpoint 1
40291 Assignment 0 6 0 Read/Write
0 = None, 1 = Counter A, 2 = Counter B, 3 = Counter C, 4 =
Rate A, 5 = Rate B, 6 = Rate C
40292 Action 0 3 0 Read/Write 0 = No, 1 = Latch, 2 = Timed Out, 3 = Boundary
40293 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40294 Annunciator 0 3 0 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40295 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red, 4 = Grn/Org,
5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color
40296 Tracking 0 7 0 Read/Write
0 = No, 1 = S1, 2 = S2, 3 = S3, 4 = S4, 5 = CntLd A,
6 = CntLd B, 7 = CntLd C
40297 Power-up State 0 2 0 Read/Write 0 = Off, 1 = On, 2 = Save
40298 Activation Type 0 1 0 Read/Write 0 = Low Acting, 1 = High Acting
40299 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40300 Hysteresis 0 59999 0 Read/Write 1 = 1 Display Unit
40301 On Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40302 Off Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40303 Output Time-out 0 59999 100 Read/Write 1 = 0.01 Second
40304 Rate Timed Output One-Shot 0 1 0 Read/Write 0 = No, 1 = Yes
40305 Counter Auto Reset 0 4 0 Read/Write
0 = No, 1 = Zero at Start, 2 = CntLd at Start, 3 = Zero at End,
4 = CntLd at End
40306 Output Reset with Counter Reset 0 1 0 Read/Write 0 = No, 1 = Yes
40307 Output Reset at Sn+1 0 2 0 Read/Write 0 = No, 1 = Reset at Sn+1 Start, 2 = Reset at Sn+1 End
Setpoint 2
40311 Assignment 0 6 0 Read/Write
0 = None, 1 = Counter A, 2 = Counter B, 3 = Counter C,
4 = Rate A, 5 = Rate B, 6 = Rate C
40312 Action 0 3 0 Read/Write 0 = No, 1 = Latch, 2 = Timed Out, 3 = Boundary
40313 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40314 Annunciator 0 3 0 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40315 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red, 4 = Grn/
Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color
40316 Tracking 0 7 0 Read/Write
0 = No, 1 = S1, 2 = S2, 3 = S3, 4 = S4, 5 = CntLd A,
6 = CntLd B, 7 = CntLd C
40317 Power-up State 0 2 0 Read/Write 0 = Off, 1 = On, 2 = Save
40318 Activation Type 0 1 0 Read/Write 0 = Low Acting, 1 = High Acting
40319 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40320 Hysteresis 0 59999 0 Read/Write 1 = 1 Display Unit
40321 On Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40322 Off Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40323 Output Time-out 0 59999 100 Read/Write 1 = 0.01 Second
40324 Rate Timed Output One-Shot 0 1 0 Read/Write 0 = No, 1 = Yes
40325 Counter Auto Reset 0 4 0 Read/Write
0 = No, 1 = Zero at Start, 2 = CntLd at Start, 3 = Zero at End,
4 = CntLd at End
40326 Output Reset with Counter Reset 0 1 0 Read/Write 0 = No, 1 = Yes
40327 Output Reset at Sn+1 0 2 0 Read/Write 0 = No, 1 = Reset at Sn+1 Start, 2 = Reset at Sn+1 End
Setpoint 3
40331 Assignment 0 6 0 Read/Write
0 = None, 1 = Counter A, 2 = Counter B, 3 = Counter C,
4 = Rate A, 5 = Rate B, 6 = Rate C
40332 Action 0 3 0 Read/Write 0 = No, 1 = Latch, 2 = Timed Out, 3 = Boundary
40333 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40334 Annunciator 0 3 0 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40335 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red, 4 = Grn/
Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color
40336 Tracking 0 7 0 Read/Write
0 = No, 1 = S1, 2 = S2, 3 = S3, 4 = S4, 5 = CntLd A,
6 = CntLd B, 7 = CntLd C
40337 Power-up State 0 2 0 Read/Write 0 = Off, 1 = On, 2 = Save
40338 Activation Type 0 1 0 Read/Write 0 = Low Acting, 1 = High Acting
40339 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40340 Hysteresis 0 59999 0 Read/Write 1 = 1 Display Unit
40341 On Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40342 Off Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40343 Output Time-out 0 59999 100 Read/Write 1 = 0.01 Second
40344 Rate Timed Output One-Shot 0 1 0 Read/Write 0 = No, 1 = Yes
40345 Counter Auto Reset 0 4 0 Read/Write
0 = No, 1 = Zero at Start, 2 = CntLd at Start, 3 = Zero at End,
4 = CntLd at End
