red lion PAX2D User Manual

30
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
40346 Output Reset with Counter Reset 0 1 0 Read/Write 0 = No, 1 = Yes
40347 Output Reset at Sn+1 0 2 0 Read/Write 0 = No, 1 = Reset at Sn+1 Start, 2 = Reset at Sn+1 End
Setpoint 4
40351 Assignment 0 6 0 Read/Write
0 = None, 1 = Counter A, 2 = Counter B, 3 = Counter C,
4 = Rate A, 5 = Rate B, 6 = Rate C
40352 Action 0 3 0 Read/Write 0 = No, 1 = Latch, 2 = Timed Out, 3 = Boundary
40353 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse
40354 Annunciator 0 3 0 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash
40355 Color 0 7 0 Read/Write
0 = No Change, 1 = Green, 2 = Orange, 3 = Red, 4 = Grn/
Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color
40356 Tracking 0 7 0 Read/Write
0 = No, 1 = S1, 2 = S2, 3 = S3, 4 = S4, 5 = CntLd A,
6 = CntLd B, 7 = CntLd C
40357 Power-up State 0 2 0 Read/Write 0 = Off, 1 = On, 2 = Save
40358 Activation Type 0 1 0 Read/Write 0 = Low Acting, 1 = High Acting
40359 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes
40360 Hysteresis 0 59999 0 Read/Write 1 = 1 Display Unit
40361 On Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40362 Off Time Delay 0 59999 0 Read/Write 1 = 0.01 Second
40363 Output Time-out 0 59999 100 Read/Write 1 = 0.01 Second
40364 Rate Timed Output One-Shot 0 1 0 Read/Write 0 = No, 1 = Yes
40365 Counter Auto Reset 0 4 0 Read/Write
0 = No, 1 = Zero at Start, 2 = CntLd at Start, 3 = Zero at End,
4 = CntLd at End
40366 Output Reset with Counter Reset 0 1 0 Read/Write 0 = No, 1 = Yes
40367 Output Reset at Sn+1 0 2 0 Read/Write 0 = No, 1 = Reset at Sn+1 Start, 2 = Reset at Sn+1 End
Analog Output
40371 Type 0 2 1 Read/Write 0 = 0-20 mA, 1 = 4-20 mA, 2 = 0-10 V
40372 Assignment 0 12 0 Read/Write
0 = None, 1 = Counter A, 2 = Counter B, 3 = Counter C,
4 = Rate A, 5 = Rate B, 6 = Rate C, 7 = Hi (max),
8 = Lo (min), 9 = S1, 10 = S2, 11 = S3, 12 = S4
40373 Analog Low Scale Value (Hi word)
-199999 999999 0 Read/Write Display value that corresponds with 0 V, 0 mA or 4 mA output
40374 Analog Low Scale Value (Lo word)
40375 Analog High Scale Value (Hi word)
-199999 999999 10000 Read/Write Display value that corresponds with 10 V or 20 mA output
40376 Analog High Scale Value (Lo word)
DISPLAY PARAMETERS SEE DISPLAY MODULE FOR PARAMETER DESCRIPTIONS
Line 1
40381 Line 1 Display Color 0 2 0 Read/Write 0 = Green, 1 = Red, 2 = Orange
40382 Display Intensity Level 1 4 4 Read/Write 1 = Min., 4 = Max.
40383 Display Contrast Level 0 15 7 Read/Write
40384 Line 1 Display Value Enable 0 255 1 Read/Write
Bit State: 0 = No (Disabled), 1 = Yes (Enabled) Bit 0 = Count
A, Bit 1 = Count B, Bit 2 = Count C, Bit 3 = Rate A, Bit 4 =
Rate B, Bit 5 = Rate C, Bit 6 = Hi (max), Bit 7 = Lo (min)
40385 Line 1 Display Scroll Enable/Time 0 15 0 Read/Write 0 = No Scroll, 1-15 = Scroll Time in Seconds
40386 Line 1 Units Mnemonic Mode 0 3 3 Read/Write 0 = Off, 1 = Label, 2 = Custom, 3 = Factory
40387 Line 1 Units Mnemonic Digit 1 (Left) 0 57 0 Read/Write
Label Mnemonic Mode only. Active List (A or B).
0 = 9 = I 18 = Q 27 = Z 36 = 8 45 = m(r) 54 = ]
1 = A 10 = J 19 = R 28 = 0 37 = 9 46 = o 55 = /
2 = b 11 = K 20 = S 29 = 1 38 = a 47 = q 56 = °
3 = C 12 = L 21 = t 30 = 2 39 = c 48 = r 57 = _
4 = d 13 = M(l) 22 = U 31 = 3 40 = e 49 = u
5 = E 14 = M(r) 23 = V 32 = 4 41 = g 50 = w(r)
6 = F 15 = N 24 = W(l) 33 = 5 42 = h 51 = -
7 = G 16 = O 25 = W(r) 34 = 6 43 = i 52 = =
8 = H 17 = P 26 = Y 35 = 7 44 = n 53 = [
40388 Line 1 Units Mnemonic Digit 2 (Center) 0 57 0 Read/Write Label Mnemonic Mode only. Active List (A or B).
40389 Line 1 Units Mnemonic Digit 3 (Right) 0 57 0 Read/Write Label Mnemonic Mode only. Active List (A or B).
Line 2
40401 Line 2 Security Code Value 0 250 0 Read/Write
40402 Line 2 Display Scroll Enable/Time 0 15 0 Read/Write 0 = No Scroll, 1-15 = Scroll Time in Seconds
40403 Line 2 Units Mnemonic Mode 0 7 3 Read/Write
0 = Off, 1 = Label, 2 = Custom, 3 = Factory, 4 = Label &
Custom, 5 = Label & Factory, 6 = Line 1 Indexed Label, 7 =
Line 1 Indexed Label & Factory
40404 Line 2 Units Mnemonic Digit 1 (Left) 0 54 0 Read/Write
Label Mnemonic Mode.
0 = 9 = I 18 = q 27 = 0 36 = 9 45 = o 54 = _
1 = A 10 = J 19 = r 28 = 1 37 = a 46 = u
2 = b 11 = k 20 = S 29 = 2 38 = c 47 =
w(r)
3 = C 12 = L 21 = t 30 = 3 39 = e 48 = -
4 = d 13 = M(l) 22 = U 31 = 4 40 = g 49 = =
5 = E 14 = M(r) 23 = W(l) 32 = 5 41 = h 50 = [
6 = F 15 = N 24 = W(r) 33 = 6 42 = i 51 = ]
7 = G 16 = O 25 = Y 34 = 7 43 = n 52 = /
8 = H 17 = P 26 = Z 35 = 8 44 = m(r) 53 = °
40405 Line 2 Units Mnemonic Digit 2 0 54 0 Read/Write Label Mnemonic Mode only. Active List (A or B).
