32
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
40504 Line 1 Display (Top Line) 0 8 1 Read/Write
0 = No Display, 1 = Count A, 2 = Count B, 3 = Count C, 4 =
Rate A, 5 = Rate B, 6 = Rate C, 7 = Max (Hi), 8 = Min (Lo)
40505 Line 2 Display (Bottom Line) 0 13 0 Read/Write
0 = No Display, 1 = Count A, 2 = Count B, 3 = Count C, 4 =
Rate A, 5 = Rate B, 6 = Rate C, 7 = Max (Hi), 8 = Min (Lo), 9
= List A/B, 10 = S1, 11 = S2, 12 = S3, 13 = S4
UNITS MNEMONICS
List A List B Line 1 Units Label Mode (A/B List)
SEE USER LIST FUNCTION IN INPUT MODULE FOR DETAILS
40601 40801 Line 1 Units Mnemonic Digit 1 (Left) 0 57 0 Read/Write
Label Mnemonic Mode only. Active List (A or B).
0 = 9 = I 18 = Q 27 = Z 36 = 8 45 = m(r) 54 = ]
1 = A 10 = J 19 = R 28 = 0 37 = 9 46 = o 55 = /
2 = b 11 = K 20 = S 29 = 1 38 = a 47 = q 56 = °
3 = C 12 = L 21 = t 30 = 2 39 = c 48 = r 57 = _
4 = d 13 = M(l) 22 = U 31 = 3 40 = e 49 = u
5 = E 14 = M(r) 23 = V 32 = 4 41 = g 50 = w(r)
6 = F 15 = N 24 = W(l) 33 = 5 42 = h 51 = -
7 = G 16 = O 25 = W(r) 34 = 6 43 = i 52 = =
8 = H 17 = P 26 = Y 35 = 7 44 = n 53 = [
40602 40802 Line 1 Units Mnemonic Digit 2 0 57 0 Read/Write
40603 40803 Line 1 Units Mnemonic Digit 3 (Right) 0 57 0 Read/Write
List A List B Line 1 Units Custom Mode (A/B List)
40604 40804 Counter A Mnemonic - Digit 1 (Left) 0 57 0 Read/Write Custom Mnemonic Mode.
40605 40805 Counter A Mnemonic - Digit 2 (Center) 0 57 0 Read/Write
40606 40806 Counter A Mnemonic - Digit 3 (Right) 0 57 0 Read/Write
40607 40807 Counter B Mnemonic - Digit 1 0 57 0 Read/Write
40608 40808 Counter B Mnemonic - Digit 2 0 57 0 Read/Write
40609 40809 Counter B Mnemonic - Digit 3 0 57 0 Read/Write
40610 40810 Counter C Mnemonic - Digit 1 0 57 0 Read/Write
40611 40811 Counter C Mnemonic - Digit 2 0 57 0 Read/Write
40612 40812 Counter C Mnemonic - Digit 3 0 57 0 Read/Write
40613 40813 Rate A Mnemonic - Digit 1 0 57 0 Read/Write
40614 40814 Rate A Mnemonic - Digit 2 0 57 0 Read/Write
40615 40815 Rate A Mnemonic - Digit 3 0 57 0 Read/Write
40616 40816 Rate B Mnemonic - Digit 1 0 57 0 Read/Write
40617 40817 Rate B Mnemonic - Digit 2 0 57 0 Read/Write
40618 40818 Rate B Mnemonic - Digit 3 0 57 0 Read/Write
40619 40819 Rate C Mnemonic - Digit 1 0 57 0 Read/Write
40620 40820 Rate C Mnemonic - Digit 2 0 57 0 Read/Write
40621 40821 Rate C Mnemonic - Digit 3 0 57 0 Read/Write
40622 40822 Max (Hi) Mnemonic - Digit 1 0 57 0 Read/Write
40623 40823 Max (Hi) Mnemonic - Digit 2 0 57 0 Read/Write
40624 40824 Max (Hi) Mnemonic - Digit 3 0 57 0 Read/Write
40625 40825 Min (Lo) Mnemonic - Digit 1 0 57 0 Read/Write
40626 40826 Min (Lo) Mnemonic - Digit 2 0 57 0 Read/Write
40627 40827 Min (Lo) Mnemonic - Digit 3 0 57 0 Read/Write
List A List B Line 2 Units Label Mode (A/B List)
40628 40828 Line 2 Units Mnemonic Digit 1 (Left) 0 54 0 Read/Write
Label Mnemonic Mode.
0 = 9 = I 18 = q 27 = 0 36 = 9 45 = o 54 = _
1 = A 10 = J 19 = r 28 = 1 37 = a 46 = u
2 = b 11 = k 20 = S 29 = 2 38 = c 47 =
w(r)
3 = C 12 = L 21 = t 30 = 3 39 = e 48 = -
4 = d 13 = M(l) 22 = U 31 = 4 40 = g 49 = =
5 = E 14 = M(r) 23 = W(l) 32 = 5 41 = h 50 = [
6 = F 15 = N 24 = W(r) 33 = 6 42 = i 51 = ]
7 = G 16 = O 25 = Y 34 = 7 43 = n 52 = /
8 = H 17 = P 26 = Z 35 = 8 44 = m(r) 53 = °
40629 40829 Line 2 Units Mnemonic Digit 2 0 54 0 Read/Write
40630 40830 Line 2 Units Mnemonic Digit 3 0 54 0 Read/Write
40631 40831 Line 2 Units Mnemonic Digit 4 0 54 0 Read/Write
40632 40832 Line 2 Units Mnemonic Digit 5 0 54 0 Read/Write
40633 40833 Line 2 Units Mnemonic Digit 6 0 54 0 Read/Write
40634 40834 Line 2 Units Mnemonic Digit 7 0 54 0 Read/Write
40635 40835 Line 2 Units Mnemonic Digit 8 0 54 0 Read/Write
40636 40836 Line 2 Units Mnemonic Digit 9 (Right) 0 54 0 Read/Write
List A List B Line 2 Units Custom Mode (A/B List)
40637 40837 Counter A Mnemonic - Digit 1 (Left) 0 54 0 Read/Write Custom Mnemonic Mode.
40638 40838 Counter A Mnemonic - Digit 2 0 54 0 Read/Write
40639 40839 Counter A Mnemonic - Digit 3 0 54 0 Read/Write
40640 40840 Counter A Mnemonic - Digit 4 0 54 0 Read/Write
40641 40841 Counter A Mnemonic - Digit 5 0 54 0 Read/Write
40642 40842 Counter A Mnemonic - Digit 6 0 54 0 Read/Write
