red lion PAXD Series User Manual

2
Ordering Information . . . . . . . . . . . . . . . . . . 2
General Meter Specifications . . . . . . . . . . . . 3
Universal DC Input Panel Meter . . . . . . . . . . 4
Process Input Panel Meter . . . . . . . . . . . . . . 4
AC True RMS Voltage and Current Meter . . . 5
Strain Gage Input Panel Meter . . . . . . . . . . . 5
Thermocouple and RTD Input Meter . . . . . . 6
Optional Plug-In Cards . . . . . . . . . . . . . . . . . 7
Installing the Meter . . . . . . . . . . . . . . . . . . . . 8
Setting the Jumpers . . . . . . . . . . . . . . . . . . . 8
Wiring the Meter . . . . . . . . . . . . . . . . . . . . . 10
Reviewing the Front Buttons and Display . . 13
Programming the Meter . . . . . . . . . . . . . . . 14
Factory Service Operations . . . . . . . . . . . . 23
Parameter Value Chart . . . . . . . . . . . . . . . . 25
Programming Overview . . . . . . . . . . . . . . . 27
TABLE OF CONTENTS
ORDERING INFORMATION
PAX
0
0
D - DC Volt/ Current Input
P - Process Input
H - AC True RMS Volt/Current Input *
S - Strain Gage/Bridge Input
T - Thermocouple and RTD Input
0 - Red, Sunlight Readable Display
1 - Green Display
0 - 85 to 250 VAC
1 - 11 to 36 VDC, 24 VAC
* PAXH is only available with 85-250 VAC power supply.
Meter Part Numbers
Option Card and Accessories Part Numbers
SFCRD200Crimson 2 PC Configuration Software for Windows 98, ME, 2000 and XPSFCRD*
Accessories
PAXLBK10Units Label Kit Accessory (Not required for PAXT)PAXLBK
PAXCDC4C
PAXCDC40
PAXCDC30
Extended Modbus Communications Card with Dual RJ11 Connector
Modbus Communications Card
DeviceNet Communications Card
Optional
Plug-In
Cards
PAXCDC50
PAXCDL10
Profibus-DP Communications Card
Analog Output CardPAXCDL
PAXCDC2C
PAXCDC20
Extended RS232 Serial Communications Output Card with 9 Pin D Connector
RS232 Serial Communications Output Card with Terminal Block
PAXCDC1C
PAXCDC10
PAXCDC
PAXCDS40Quad Setpoint Sourcing Open Collector Output Card
PAXCDS30Quad Setpoint Sinking Open Collector Output Card
PAXCDS20Quad Setpoint Relay Output Card
TYPE
PAXCDS10Dual Setpoint Relay Output Card
PAXCDS
PART NUMBERSDESCRIPTIONMODEL NO.
*Crimson
®
software is available for download from http://www.redlion.net/
RS485 Serial Communications Output Card with Terminal Block
Extended RS485 Serial Communications Output Card with Dual RJ11 Connector
