Redarc BCDC1220 User Manual

CONTENTS
Table of Contents Page
Warnings and Safety Instructions 01
Contents 02
Specifi cations 02
1 Product Function 03
1. Operation 03
2. Turn On/Off Thresholds 03
3. Display Panel 04
2 Installation 04
1. Wiring 06
3 Two Year Warranty 10
Specifi cations
BCDC1220
DC Input Voltage Range 9V-32V
Gel/AGM Std Lead Acid Calcium Content
Absorption Voltage 14.5V 14.9V 15.3V
Float Voltage 13.3V 13.3V 13.3V
No Load Current <100mA
Standby Current <5mA
Input Fuse Rating 12V/24V 30A/20A (Not supplied)
Output Fuse Rating 30A (Not supplied)
Output Power 300W
Ambient Temperature -20°C to +80°C
Minimum O/P Battery Volts 3V
Weight 450g
Dimensions 100x120x37mm
Warranty 2 years
Standards CE, C-Tick, AS/NZS CISPR11:2004
2

Redarc BCDC1220 Specifications

General

Input Voltage	9 - 32VDC
Output Voltage	12V DC
Output Current	20A
Dimensions	150mm x 120mm x 37mm
Weight	0.65 kg
Battery Types Supported	AGM, Gel, Calcium
Charger Type	DC to DC
Protection Features	Over Temperature, Short Circuit, Reverse Polarity
