2 USER GUIDE
2.2.5 DC Input Terminal (All Models)
• Connect DC input terminal to 12V / 24V battery or the other power sources.
• POS(+) represents positive, and NEG(-) represents negative.
• The Inverter is protected against reverse polarity connection using an internal fuse.
Model
DC Input Voltage
Minimum Maximum
12V 10.5 15.0
24V 21.0 30.0
2.2.6 Chassis Ground
The Chassis Ground terminal should be connected to the vehicle Chassis using 7.5mm² cable as
a minimum.
WARNING
Operating the inverter without a proper ground connection may cause an electrical
hazard.
11

