1 INTRODUCTION
1.3 Dimensions
Dimension
350S
700S
1000S
1500S
2000S
3000S
A
180mm
270mm
340mm
370mm
370mm
400mm
B
125mm
150mm
150mm
160mm
180mm
180mm
C
60mm
70mm
85mm
85mm
165mm
165mm
D
145mm
175mm
180mm
190mm
210mm
210mm
E
132mm
195mm
195mm
195mm
245mm
245mm
F
135mm
160mm
165mm
175mm
195mm
195mm
G
6mm
8mm
8mm
8mm
9mm
9mm
A
B
C
D
F
E
G
5
7
Table of Contents
Warnings and Safety Instructions
2
Table of Contents
3
Contents
3
Introduction
4
Specifi Cations
4
Specifi Cations
5
Dimensions
6
USER Guide
7
Front Panel Operation
7
Front Panel View
7
On/Off/Remote Switch (700W - 3000W)
8
Input Level LED Display (700W - 3000W)
8
Load Level Display (700W - 3000W)
8
Status LED Displayc (All Models)
9
Power Saving Mode Settings (700W - 3000W)
9
AC Frequency Setting (All Models)
10
Rear Panel Operations
10
Rear Panel View
10
On/Off/Remote Switch (350W Only)
11
Remote Port (700W - 3000W)
11
Ventilation Fan
11
DC Input Terminal (All Models)
12
Chassis Ground
12
INSTALLATION Guide
13
Mounting
13
DC Wiring Connections (700W - 3000W)
13
DC Cable Size
14
Wiring Diagrams
15
DC Cable Connection (700W - 3000W)
16
1500W DC Connection Method
16
AC Safety Grounding
17
Inverter First Operation
17
Maintenance
17
Troubleshooting
18
Two Year Warranty
19
5
