Redarc R-12-350S User Manual

1 INTRODUCTION
1.1 12V Specifi cations
Specifi cation R-12-350S R-12-700S R-12-1000S R-12-1500S R-12-2000S R-12-3000S
Output Power (Cont.)
350W 700W 1000W 1500W 2000W 3000W
Output Power (Max.)
385W 770W 1100W 1650W 2200W 3300W
Surge Rating (Max.)
700W 1400W 2000W 3000W 4000W 6000W
Input Voltage (Nom.)
12V 12V 12V 12V 12V 12V
Input Voltage (Min.)
10.5V 10.5V 10.5V 10.5V 10.5V 10.5V
Input Voltage (Max.)
15V 15V 15V 15V 15V 15V
Output Voltage
220/ 230/ 240V AC ± 3%
Frequency
50 / 60Hz ± 0.05%
Output Waveform
Pure Sine Wave (THD < 3%)
Effi ciency (full load)
91.0% 91.0% 91.0% 90.0% 91.0% 90.0%
No Load Current Draw
1.20A 1.25A 1.40A 2.64A 2.80A
Stand-By Current Draw
0.25A 0.25A 0.28A 0.60A 0.55A
Input Voltage Regulation
10.5V - 15.0V
Input Level Indicator
N/A Red/ Orange/ Green LEDs
Load Level Indicator
N/A Red/ Orange/ Green LEDs
Failure Indicator
Red LED
Protection
Overload, Short Circuit, Reverse Polarity (Fuse), Over/Under Voltage, Over Temp.
Remote Control Unit
Hardwire CR-6 12 / CR-8
Safety Certifi cate
EN60950-1
EMC
EN55022:1997, EN55024: 1997, EN61000-3-2: 1998, EN61000-3-3: 1995
Operating Temp.
0 - 40°C
Cooling
Loading Controlled Cooling Fan
Protection Features for 12V Inverters
Over Voltage Shutdown
15.3V
Over Voltage Restart
14.3V
Under Voltage Alarm
11.0V
Under Voltage Shutdown
10.2V
Under Voltage Restart
12.7V
Over Temperature Shutdown (Interior)
70°C
Over Temperature Restart (Interior)
45°C
Over Temperature Shutdown (Heat Sink)
90°C
Over Temperature Restart (Heat Sink)
60°C
3

Redarc R-12-350S Specifications

General

Brand	Redarc
Model	R-12-350S
Category	Inverter
Language	English
