3 INSTALLATION
3.4 DC Cable Connection (700W - 3000W)
3.4.1 700W - 1500W DC Connection method
3.4.2 2000W - 3000W DC Connection method
15
M8 Screw
Ring Terminal
PVC Wire
M8 Nut
Spring Washer
Washer
Ring Terminal
PVC Wire
Plastic Cover
(Black)
Plastic Cover
(Black)
