7
2 USER GUIDE
2.1.2 On/Off/Remote Switch (700W - 3000W)
This switch acts as an On - Off switch and can also set the unit to remote mode allowing the On
- Off functionality to be performed by either the CR-6 or CR-8 remote control.
Usage:
a. Before installing the inverter, you need to ensure the main switch is set to “OFF”.
b. Before using the remote unit, you need to ensure the main switch is set to “REMOTE”.
2.1.3 Input Level LED Display (700W - 3000W)
The Input Level LED Display is designed to advise the user of the DC Input Voltage Level. The
Input Level LED will display the Input Voltage Level using this sequence of fl ashes and colours
on the LED.
LED Status 12V Inverters 24V Inverters
RED Slow Blink
10.3 - 10.6 20.5 - 21.2
RED
10.6 - 11.0 21.2 - 21.8
ORANGE
11.0 - 12.1 21.8 - 24.1
GREEN
12.1 - 14.2 24.1 - 28.6
ORANGE Blink
14.2 - 15.0 28.6 - 30.0
RED Blink
> 15.0 > 30.3
2.1.4 Load Level Display (700W - 3000W)
The Load Level LED Display is designed to advise the user of the currently supplied AC Wattage.
The Load Level LED will display the Loaded Wattage using this sequence of fl ashes and colours
on the LED.
LED Status 700W 1000W 1500W 2000W 3000W
DARK
0-56W 0-80W 0-120W 0-160W 0-240W
GREEN
56-230W 80-330W 120-495W 160-660W 240-990W
ORANGE
230-525W 330-750W 495-1125W 660-1500W 990-2250W
RED
525-672W 750-960W 1125-1450W 1500-1920W 2250-2880W
RED Blink
> 672W > 960W > 1450W > 1920W > 2880W
