RedMax GZ25N - 6-2 Removing of Clunch Shoe

11
STRATO CHARGED ENGINE  GZ25N
Wave
Washer
ClutchShoe
Arrowmarksonthe
uppersurface
6. SERVICE GUIDE
6-2 Removing of Clunch Shoe
Removethehousingandplugcap.
Removethesparkplugandfitthestopper(4810-
96220)intotheplughole.
Removeclutchbolts(14mmHex.).
Removetherotornut(12mmHex.).
Removetherotorusingthepullerassy(2890-
96100).Apply8mmpullerbolts.
6-3 Mounting of Clutch Shoe
6-4 Removing of Rotor
Applygreaseintotheholesontheclutchshoe
beforemountingtheclutch.
 Grease:Molybdenumgrease
 Clutchboltfixingtorque:5080kg.cm(43-69in.lbs）
Stopper
ClutchBolt(14mmHex
.)
RotorNut
Pulle
r
Pullerbol
ts
Rotor
17mmHex.
ClutchShoe
Grease
Caution:
Care for orientation of the wave washers and clutch
shoe.
