RedMax GZ25N - 3 Outline Drawing

6
STRATO CHARGED ENGINE  GZ25N
3. OUTLINE DRAWING
Unit:mm(in.)
Engine Cover
Muffler
Tank Guard
Fuel Tank
Fuel Cap
Air Cleane
Carburetor
Plug Cap
Recoil Starter
Fan Cover
Fan Cover
122
(
4.80
)
223
(
8.78
)
168
(
6.61
)
238
(
9.36
)
271
(
10.67
)
85
(
3.35
)
7.85
(
0.31
)
155
(
6.10
)
188
(
7.40
)
113
(
4.45
)
248
(
9.76
)
113
(
4.45
)
248
(
9.76
)
GZ25N for
BCZ2500S, BCZ2500SU,
LRTZ2500, SRTZ2500,
PSZ2500, RMSZ2500,
HEZ2500S and EXZ2500S.
GZ25N2 for
SGCZ2500S.
