RedMax GZ25N - Laying of Switch Cable; Fitting of Plug Cap; Removing Piston Pin

13
STRATO CHARGED ENGINE  GZ25N
6. SERVICE GUIDE
6-8 Laying of Switch Cable
Fittheleadwireswiththeclipsonthesideofthe
coil.Confirmthattheydonottouchwiththerotor.
6-9 Fitting of Plug Cap
Inserttheguideoftheplugcapintotheengine
coversecurely.
Caution:
Check that the plug cap is not deteriorated, stiffened,
nor has cracks.
Also check that there is no play after fitting the cap.
6-10 Removing Piston Pin
Removesnapringsfrombothsidesofthepiston
pin.
Engagetherodassy(1101-96220)tothepiston
pinandgentlytapwithaplastichammertopush
outthepin.
Caution:
Hard hammering may damage the big end of the
connecting rod.
Red
Black
Clip
Coil
EngineCover
Plugcapguide
PlasticHammer
RodAssy
Pisto
n
