STRATO CHARGED ENGINE  GZ25N
6. SERVICE GUIDE
6-15 Assembling of Cylinder Plate
Anotchonthecylinderplateistolaythehighten-
sioncable.
Setthecylinderplatewiththenotchatthemuffler
side.
6-14 Positioning of Lead Air Intake Tube
Theleadairintaketubehascastmarkingofeither
ForS.
Sisforthestarterend,andFforthefanend.
Assemblingpositionshallnotbemixedup.
Caution:
Oppositely assembled tubes will cause a sealing failure.
Before assembling the tubes, check for deterioration or
cracks and change with new ones if necessary.
Marks
Leadairintaketube
6-16 Setting of Insulator Gasket
Settheinsulatorgasketundertheenginecoverwith
carefornotturningitupbytheenginecover.
InsulatorGasket
Mufflerside
Notch
CylinderPlate
