RedMax GZ25N - 6-6 Assembling of Ignition Coil; 6-7 Installing of Spark Plug

12
STRATO CHARGED ENGINE  GZ25N
6. SERVICE GUIDE
6-6 Assembling of lgnition Coil
Insertthegauge(3350-96240)inbetweentherotor
magnetmetalandthecoil.Tightenscrewswhile
pressingthecoilagainsttherotor.
Gapspecification0.30.4mm(0.0120.016in.)
Removetherecoilstarterandthesparkplug.
Insertthestopper(4810-96220)totheplughole.
Engagethepuller(4500-96100)to2holeson
thepulleyandpulloutthepulley.
Note:
Pulley screw is right turn screw.
6-5 Removing Recoil Pulley
Pulley
Pulle
r
Wrench
Ignitioncoil
Gauge
6-7 Installing of Spark Plug
Thesparkplugnutis16mmhex.sothatconven-
tionalplugwrench(19mm)cannotbeused.
Makesuretousethecustomplugwrench.
Important:
Fixing the spark plug using other tools than the
custom plug wrench may apply over torque and end
up with damages of threads on the cylinder.
16mm
