Reebok Competitor RT5.1 - 2 Bolt (9) and a 3;8 Nut (10). Do Not over; Tighten the Nut; the Wheel Must Turn Freely; Press a Base Cap (110) into the Base (91

9
4. Hold the Right Upright (81) against the Base
(91). Be careful not to pinch the Upright Wire
(88). Insert two 3/8" x 4" Screws (7) and a 3/8" x
1 1/2" Screw (8) with three 3/8" Star Washers
(11) into the Right Upright.
Partially tighten the 3/8" x 4" Screws (7) until
the heads of the Screws touch the Right Upright
(81); do not fully tighten the Screws yet.
Partially tighten the 3/8" x 1 1/2" Screw (8).
91
81
88
11
11
8
7
4
5. With the help of a second person, carefully tip
the treadmill onto its right side. Partially fold the
Frame (53) so that the treadmill is more stable;
do not fully fold the Frame yet.
Attach a Wheel (93) to the Base (91) with a 3/8"
x 2" Bolt (9) and a 3/8" Nut (10). Do not over-
tighten the Nut; the Wheel must turn freely.
Press a Base Cap (110) into the Base (91).
5
9
53
10
91
110
93
