Reebok RBX 550 - How to Set up the Treadmill

6
1. With the help of a second person, carefully raise the
Uprights (39) until the treadmill is in the position shown.
2. Make sure the Lock Knob Sleeve (18) is pressed into the
left Upright (39).
Make sure that the two Lock Pin Collars (20) and the
Spring (19) are on the Lock Pin (49). Insert the Lock Pin
into the Lock Knob Sleeve (18) and the left Upright (39).
Tighten the Lock Knob (17) onto the Lock Pin.
3. Make sure that all parts are tightened before you use the treadmill. Place a mat under the treadmill to
protect the floor or carpet.
39
1
2
Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials
until setup is completed. No tools are required.
HOW TO SET UP THE TREADMILL
39
18
17
19
20
49
