Reed Instruments R5001 User Manual

12
www.REEDINSTRUMENTS.com
Operating Instructions
Power ON/OFF
To turn the meter on or off, press the power button. By default, the meter
issettoAutoLCRSmartmodewithatestfrequencyof1kHz.
Auto Power Off
To preserve battery life, the meter is programmed to turn off after 5 minutes of
inactivity and 3 warning beeps. If a button is pushed during the three beeps,
the meter will continue measuring. To turn this feature on and off, press the
APObutton.Whenenabled,"APO"willappearonthedisplay.
Beep Function
This meter will beep once if the function selected is available, and beep
twice if the function selected is unavailable.
u = Active Functions
Button FUNC HOLD
DQθ
S/P BKLIT SORT REL% FREQ
AUTOLCR
u u u u
L
u u u u u u u u
C
u u u u u u u u
ACR
u u u u u u u
DCR
u u u u u
Backlight
Press the Backlight Button to turn the backlight on or off. The backlight
will stay on for 60 seconds before turning off automatically.
Battery Charge
The three horizontal bars above the battery symbol on the LCD screen
indicate the charge left in the batteries. When the three bars are no longer
visiblethebatteriesneedreplacement.See"Battery Replacement" for details.
continued...
