Reed Instruments R5001 User Manual

5
www.REEDINSTRUMENTS.com
Included
• TestLeadsandProbes
• Tweezers
• AlligatorClips
• Batteries
Specifications
TestFrequencies: 100/120/1k/10k/100kHz
Test AC Signal Level: 0.6mVRMS typical
TestRange(F=1kHz): L:200µHto2000H
C: 2000pF to 2mF
 R:20Ωto200MΩ
Primary Parameters Display: DCR: DC resistance
Ls: Serial inductance
Lp: Parallel inductance
Cs: Serial capacitance
Cp: Parallel capacitance
Rs: Serial resistance
Rp: Parallel resistance
Second Parameter Display: θ: Phase angle
ESR: Equivalence Serial Resistance
D: Dissipation factor
Q: Quality factor
PowerSupply: 6x1.5AABatteries
Dimensions: 8.6x3.7x2.4"(220x96x60mm)
Weight: 0.8lb(360g)
continued...
