Reed Instruments R5001 User Manual

6
www.REEDINSTRUMENTS.com
Accuracy
Notes:
• Measurementperformedatthetestsocket.
• Measurementsperformedaftercorrectopenandshortcalibration.
• DUTandtestleadsmustbeproperlyshielded.
• QvalueisthereciprocalofDF.
• Accuraciesbasedwithin10%to100%offullscaleofrange;values
outside of range should be used as reference only.
• "---"meansparallelorseriesmeasurementmode.
Inductance@Ta=18to28°C(De)
Frequency=100Hz/120Hz
Range Resolution Lx Accuracy DF Accuracy Measurement Mode
20.000mH 1µH 1.5%±10d 1.5%±50d Series
200.00mH 0.01mH 1.4%±15d 1.4%±50d Series
2000.0mH 0.1mH 1.5%±15d 1.5%±50d Series
20.000H 1mH 1.6%±10d 1.6%±50d ---
200.00H 0.01H 1.3%±10d 1.3%±50d Parallel
2000.0H 0.1H 2.0%±15d 2.0%±50d Parallel
20.000kH 0.001kH 2.5%±15d 2.5%±50d Parallel
Frequency=1kHz
Range Resolution Lx Accuracy DF Accuracy Measurement Mode
2000.0µH 0.1µH 1.3%±10d 1.3%±50d Series
20.000mH 1µH 1.2%±10d 1.2%±50d Series
200.00mH 0.01mH 1.2%±10d 1.2%±50d Series
2000.0mH 0.1mH 1.5%±15d 1.5%±50d ---
20.000H 1mH 1.5%±15d 1.5%±50d Parallel
200.00H 0.01H 2.0%±10d 2.0%±50d Parallel
2000.0H 0.1H 2.5%±15d 2.5%±50d Parallel
continued...
1.800.561.8187 info@REED-Direct.ca
REED-Direct.ca
