Reed Instruments R5001 - Page 7

7
www.REEDINSTRUMENTS.com
Frequency=10kHz
Range Resolution Lx Accuracy DF Accuracy Measurement Mode
200.00µH 0.01µH 1.8%±10d 1.8%±50d Series
2000.0uH 0.1µH 1.5%±10d 1.5%±50d Series
20.000mH 1µH 1.2%±10d 1.2%±50d Series
200.00mH 0.01mH 1.5%±15d 1.5%±50d ---
2000.0mH 0.1mH 2.0%±10d 2.0%±50d Parallel
20.000H 1mH 2.5%±15d 2.5%±50d Parallel
Frequency=100kHz
Range Resolution Lx Accuracy DF Accuracy Measurement Mode
20.000µH 0.001µH 2.5%±10d 2.5%±50d Series
200.00µH 0.01µH 1.5%±10d 1.5%±50d Series
2000.0µH 0.1µH 1.3%±15d 1.3%±50d Series
20.000mH 1µH 2.0%±15d 2.0%±50d Parallel
200.00mH 0.01mH 2.5%±15d 2.5%±50d Parallel
Capacitance@Ta=18to28°C(De)
Frequency=100Hz/120Hz
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
20.000nF 1pF 2.5%±10d 2.5%±50d Parallel
200.00nF 0.01nF 1.2%±10d 1.2%±50d ---
2000.0nF 0.1nF 0.9%±10d 0.9%±50d ---
20.000µF 1nF 1.0%±15d 1.0%±50d Series
200.00µF 0.01µF 1.2%±10d 1.2%±50d Series
2000.0µF 0.1µF 2.5%±10d 2.5%±50d Series
20.00mF 0.01mF 5.0%±10d 5.0%±50d Series
continued...
