8
www.REEDINSTRUMENTS.com
Frequency=1kHz
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
2000.0pF 0.1pF 3.5%±15d 3.5%±50d Parallel
20.000nF 1pF 1.0%±10d 1.0%±50d ---
200.00nF 0.01nF 0.9%±10d 0.9%±50d ---
2000.0nF 0.1nF 1.0%±10d 1.0%±50d Series
20.000µF 1nF 1.2%±15d 1.2%±50d Series
200.00µF 0.01µF 2.5%±10d 2.5%±50d Series
2000µF 1µF 4%±20d 4%±50d Series
Frequency=10kHz
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
200.00pF 0.01pF 3.0%±8d 3.0%±50d Parallel
2000.0pF 0.1pF 1.0%±10d 1.0%±50d ---
20.000nF 1pF 0.9%±10d 0.9%±50d ---
200.00nF 0.01nF 0.8%±10d 0.8%±50d Series
2000.0nF 0.1nF 1.0%±8d 1.0%±50d Series
20.000µF 1nF 2.0%±8d 2.0%±50d Series
200.0µF 0.1µF 4.5%±15d 4.5%±50d Series
Frequency=100kHz
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
200.00pF 0.01pF 2.5%±15d 2.5%±50d Parallel
2000.0pF 0.1pF 1.0%±8d 1.0%±50d Parallel
20.000nF 1pF 1.8%±8d 1.8%±50d Parallel
200.00nF 0.01nF 1.5%±10d 1.5%±50d Series
2000.0nF 0.1nF 2.5%±15d 2.5%±50d Series
continued...
