Resistance@Ta=18to28°C(De)
Frequency=100Hz/120Hz
Range Resolution Rx Accuracy Measurement Mode
200.00Ω 0.01Ω 1.2%±10d ---
2.0000kΩ 0.1Ω 0.8%±5d ---
20.000kΩ 1Ω 0.9%±5d ---
200.00kΩ 0.01kΩ 0.7%±3d ---
2.0000MΩ 0.1kΩ 1.0%±5d ---
20.000MΩ 1kΩ 2.2%±10d ---
200.0MΩ 0.1MΩ 2.5%±10d ---
Frequency=1kHz
Range Resolution Rx Accuracy Measurement Mode
20.000Ω 1mΩ 1.2%±10d ---
200.00Ω 0.01Ω 0.8%±5d ---
2.0000kΩ 0.1Ω 0.8%±3d ---
20.000kΩ 1Ω 0.7%±3d ---
200.00kΩ 0.01kΩ 1.0%±5d ---
2.0000MΩ 0.1kΩ 1.5%±10d ---
20.000MΩ 1kΩ 1.8%±10d ---
200.0MΩ 0.1MΩ 6.0%±50d ---
Frequency=10kHz
Range Resolution Rx Accuracy Measurement Mode
20.000Ω 1mΩ 1.5%±10d ---
200.00Ω 0.01Ω 0.8%±10d ---
2.0000kΩ 0.1Ω 0.9%±5d ---
20.000kΩ 1Ω 0.8%±3d ---
200.00kΩ 0.01kΩ 1.0%±5d ---
2.0000MΩ 0.1kΩ 2.5%±10d ---
20.00MΩ 0.01MΩ 2.8%±10d ---
continued...
