Reed Instruments R5001 User Manual

10
www.REEDINSTRUMENTS.com
Frequency=100kHz
Range Resolution Rx Accuracy Measurement Mode
20.000Ω 1mΩ 2.3%±10d ---
200.00Ω 0.01Ω 1.5%±5d ---
2.0000kΩ 0.1Ω 0.8%±20d ---
20.000kΩ 1Ω 0.8%±20d ---
200.00kΩ 0.01kΩ 1.5%±10d ---
2.000MΩ 1kΩ 2.5%±30d ---
DCResistance@Ta=18to28°C(De)
Frequency=100Hz/120Hz/1kHz/10kHz/100KHz
Range Resolution Rx Accuracy Measurement Mode
200.00Ω 0.01Ω 1.8%±10d ---
2.0000kΩ 0.1Ω 0.6%±20d ---
20.000kΩ 1Ω 0.6%±10d ---
200.00kΩ 0.01kΩ 0.5%±3d ---
2.0000MΩ 0.1kΩ 1.5%±5d ---
20.000MΩ 1kΩ 2.0%±5d ---
200.0MΩ 0.1MΩ 2.5%±5d ---
DValueAccuracy@Ta=18to28°C(De)
Freq./Z 0.1 to 1Ω 1 to 10Ω 10 to 100kΩ 100k to 1MΩ 1 to 20MΩ 20 to 200MΩ
100/120Hz ±0.03 ±0.01 0.009 ±0.010 ±0.02 ±0.04
1kHz ±0.03 ±0.01 0.009 ±0.010 ±0.02 ±0.09
10kHz ±0.03 ±0.01 0.009 ±0.009 ±0.01 ±0.04
100kHz ±0.04 ±0.03 0.010 ±0.010 ±0.02 ±0.04
θ Value Accuracy @ Ta =18 to 28°C
Freq./Z 0.1 to 1Ω 1 to 10Ω 10 to 100kΩ 100k to 1MΩ 1 to 20MΩ 20 to 200MΩ
100/120Hz ±0.65° ±0.36° ±0.23° ±0.45° ±0.65° ±1.35°
1kHz ±0.65° ±0.36° ±0.23° ±0.45° ±0.65° ±3.63°
10kHz ±0.65° ±0.36° ±0.23° ±0.45° ±1.35° N/A
100kHz ±1.27° ±0.65° ±0.49° ±0.65° ±1.35° ±1.35°
