Reed Instruments R5001 User Manual

4
www.REEDINSTRUMENTS.com
Safety
This manual should be read and well understood before the instrument is used.
• Neverattempttorepairormodifyyourinstrument.Dismantlingyour
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
• Donotoperateinanexplosiveatmosphere.
• Donotoperateinthepresenceofammablegasesorfumes.
• Keepawayfromlivecircuits.
• Donotremovetheinstrumentcover.
• Thismeterisforindooruse,altitudeupto2000m.
• Whenmeasuringin-circuitcomponents,rstde-energizethecircuits
before connecting the test leads.
• Donotmeasureacapacitorthatisnotfullydischarged.
•
When measuring within a circuit, the circuit must be de-energized before
connecting the test leads.
• Wipetheinstrumentcleanwhenusedinadustyenvironment.
•
Donotleavetheinstrumentexposedtodirectheatforlongperiodsoftime.
• Beforeremovingthebatterycover,ensurethattheinstrumentis
disconnected from any circuit and is powered OFF.
Features
• Measuresinductance,capacitanceandresistance
• AutorangingforACimpedanceandDEresistancemeasurement
• AutoLCRsmartcheckandmeasurement
• Series/Parallelmodes
• Ls/Lp/CpwithD/Q/Ø/ESRparameters
• SupportDCRmode200Ωto200MΩ
• Highaccuracywith4/5terminalKelvinmeasurement
• 10kHztestingfrequencyandupto100kHzoutputfrequency
• LargebacklitdualLCDdisplay
• Dataholdandrelativefunctions
• Lowbatteryindicationwithautopoweroff
1.800.561.8187 info@REED-Direct.ca
REED-Direct.ca

Reed Instruments R5001 Specifications

General

Brand	Reed Instruments
Model	R5001
Category	Measuring Instruments
Language	English
