REFUsol 20K-2T (853P020.200)
User manual
- 49 -
↓
Short press the“∨”
27.S1 threshold 195.5V
1500ms
↓
Short press the“∨”
27.S1: 228V 1508ms
↓
Short press the“
∨
”
27.S2 threshold 34.5V 200ms
↓
Short press the“∨”
27.S2: 227V 205ms
↓
Short press the“
∨
”
81>.S1 threshold 50.5Hz
100ms
↓
Short press the“
∨
”
81>.S1 49.9Hz 103ms
↓
Short press the“∨”
81>.S2 threshold 51.5Hz
100ms
↓
Short press the“∨”
81>.S2 49.9Hz 107ms
↓
Short press the“∨”
81<.S1 threshold 49.5Hz
100ms
↓
Short press the“∨”
81<.S1 50.0Hz 105ms
↓
Short press the“
∨
”
81<.S2 threshold 47.5Hz
100ms
↓
Short press the“
∨
”
81<.S2 50.1Hz 107ms
24. Autotest STD
19.Autotest STD
Long press the “
∨
”
The test procedure is same as Autotest Fast, but it’s much more time
consuming.
（B）Event List：
Event List is used to display the real-time event records, including the total number
of events and each specific ID No. and happening time. User can enter Event List
