SEATS/HATCH & STORAGE
Bucket Helm Seat
The bucket helm seat and optional companion bucket seat (see later
in this section) features forward and aft movement, as well as a swivel
motion that allows the seat to pivot, and a fl ip up bolster cushion that
allows any user to control his/her comfort and position.
To adjust the fore and aft helm seat position, loosen the black fore &
aft adjustment knob located amidship by turning counter clockwise.
Then slide the seat to the desired location and retighten the knob.
To swivel the seat, pull up on the swivel handle to unlock the detention
system. While the detention system is unlocked, pivot the seat to the
desired position. Be sure to lock the swivel in the detented position
by pushing down on the handle and fi nding a locked position. DO
NOT run the vessel unless the swivel is in the locked position.
To fl ip the bolster cushion up, simply grab the front cushion and pull
up.
Seat slider fasteners should periodically be checked for tightness. DO
NOT alter the seat slide system in any way.
!
CAUTION
TO PREVENT BODILY INJURY! PERIODICALLY CHECK AND
TIGHTEN THE MOUNTING BOLTS BETWEEN THE SEAT SLIDER
AND THE BUCKET SEAT BOTTOM. ALSO, CHECK THE FLOOR
INSERT BOLTS.
6-34
Equipment Operation
