12-6
GROUND BUSS
MAIN NEG
3. INSTALL CHAFE PROTECTION AS NEEDED.
2. HARNESS TO BE SECURED EVERY 18" MIN.
1. HARNESS TO BE INSTALLED AS SHOWN.
NOTES:
SENDER
LEVEL
FUEL
HALON
PUMP
BILGE
CONNECTOR
HARNESS
DECK
BLOWER
BILGE
REV. DATE:DR. BY: APP. BY:
2300 JETPORT DRIVE
ORLANDO FLORIDA 32809-7895
TELEPHONE (407) 851-4360
SCALE:
DWG. NO.:
LATEST REV LET:
APP. BY:
EFK22B
REGAL MARINE INDUSTRIES
DATE:
DR. BY:
DRAWING TITLE:
REVISION DESCRIPTION
2000 DECK TO SUMP HARNESS
12-19-02
