32
Chapter 7
10. To take the slack out of the bimini top at this time
notice the two forward canvas bows. There are two hole
adjusters in the outside bow. Put the bow in the bottom
hole for tightening up the canvas by pulling down on the
bows. Do the same with the other forward bow for the
final bimini top adjustment. Connect the adjustment straps
and fine tune.
Side Curtains
The side curtains usually are marked. Some feature col-
ored tags. Red is port and green is starboard. Zip the side
curtain to the bimini top. Next, unzip the flaps to access
the deck snaps easier. Rezip the flaps shut.
DRAWING C
DRAWING B
Aft Curtain
Zip the aft curtain to the aft connector canvas. Then snap
it completely around the stern deck. It may be easier to
accomplish the above task with the flap zipped out in
order to reach all the snaps. Finally, rezip the flap shut.
Locking Pin Resting
On Outer Bow-
Initial Adjustment
Inner Forward Bow
Outer Forward Bow
Locking Pin
Hole-Final
Adjustment
Clevis Connector
Clevis Pin
Bow Eye
