STEERING SYSTEM OVERVIEW
STERN DRIVE STEERING
Stern drive (outdrive) vessels use a rotary or rack style
steering system. This system transfers helm mechanical
energy to the engine. There is a hydraulic steering cylinder
with the help of a steering pump which sends fluid force
to the stern drive steering arm changing the course of the
boat, depending on the direction the steering wheel is
turned.
Since the steering system is the primary link for engine
control it must be periodically inspected and maintained.
The hardware at both the helm and engine locations must
be checked regularly for tightness.
Refer to the steering manufacturer’s literature in the owner’s
packet for more information along with the following
illustration.
CAUTION
!
PREVENT POSSIBLE INJURY AND/OR
PROPERTY DAMAGE!
LOOSE OR MISSING FASTENERS
COULD CAUSE DAMAGE TO THE STEERING
SYSTEM WHICH COULD RESULT IN
LOSS OF STEERING CONTROL.
PERIODICALLY CHECK ENTIRE SYSTEM.
