F5100 Regency Freestanding Woodstove
31
PARTS LIST
F5100 STOVE MAIN ASSEMBLY
6
3
5
2
9
7
8
1
4
10
11
12
14
13
15
Part # Description
1 051-539 Cast Door Assembly
2 051-004 Side Heat Shield RH
3 051-005 Side Heat Shield LH
4 Firebox Assembly
5 051-513 Pedestal Assembly
6 051-515 Rear Heat Shield Assembly
7 051-912 Airmate 8"
8 846-515 Fan-Free Standing Stove
910-157/P Replacement Motor
910-138 Auto/Manual Switch
910-140 Hi/Off/Lo switch
910-142 Fan Thermodisc
Part # Description
9 051-538 Removable Arm Assembly
10 051-018 Handle Holder
051-530 Catalytic Combustor Assembly (not shown)
063-954 Airtube 1" x 23" long
11 051-067 Thermometer
051-221 Cast Bypass Door
936-232 Gasket Bypass Door (per foot)
12 051-003 Stainless Steel Smoke Defl ector
13 156-523 Door Hinge Assembly
14 156-514 Door Catch assembly
15 156-241 Removable Cast Handle
051-006 L/R stainless steel fi rebox fi ller
919-168 Manual
