Regency F5100 - Door Assembly Parts

F5100 Regency Freestanding Woodstove
33
PARTS LIST
DOOR ASSEMBLY
7
2
4
11
12
1096
5
3
1
8
Part # Description
1 156-514 REMOVABLE CAST HANDLE ASSEMBLY
2 051-515/P ALIGNER ASSEMBLY
3 051-231 CAST DOOR METALLIC BLACK
4 948-155 HINGE PIN
5 940-384/P GLASS CERAMIC
6 936-243 TAPE 7/8 WINDOW ADHESIVE
Part # Description
7 051-058 GASKET BRACKET TOP/BOTTOM
8 051-056 GLASS / GASKET FRAME
9 936-060 5/8 MEDIUM DENSITY (936-060)
10 904-809 SCREW 1/4-20 x 3/8 TUSS HD PHIL ZINC PD (ea)
11 904-146 SCREW #10 x 1/2 SELF TAP PAN HD PHILIPS (ea)
12 0904-513 HEX BOLT 1/4-20 x 3/4 LG. (ea)
051-057 SIDE GASKET BRACKET (ea)
