P121/P121LC/P121RC/P131 Zero Clearance Room Sealed Gas Fireplace
26
INSTALLATION
327
327
Repeat step 3 on the opposite side of the burner.
Place Log 329 onto pin.
329
329
328
328
328
326
329
Grate Post
5) Place Log 329 on the middle left side of the burner. Rest the bottom
of the Log onto the second grate post from the left. Ensure that the
log fi ts into a pin that is on Log 326.
4) Embers should be placed in front of Log 326 and Log 327 and also
down the middle between the logs as shown in the image below.
Caution: Do NOT cover burner ports.
Repeat step 5 on the opposite side of the burner.
Grate Post
6) Place Log 328 on the middle right side of the burner. Ensure that the
log fi ts over the 2nd grate post from the right.
Repeat step 6 on the opposite side of the burner.
