Regin Corrigo C10 User Manual

47
Manual CORRIGO C-SERIES 2000.09
Commissioning protocol
Scheduler Factory setting Commissioning setting
Period 1 MTWTF 08:00-17:00 _______________
Period 2 _______________
Period 3 _______________
Reduced speed 1 _______________
Reduced speed 2 _______________
Reduced speed 3 _______________
Holidays 980101 _______________
Alarm settings
1. Temp deviation alarm 5K och 2 minutes ______________
2. Outdoor temp interval within which
temp deviation alarm is active 20...-20°C _______________
3. Pressure deviation alarm 50Pa / 2 minutes _______________
4. Alarm delay, supply air fan 30 seconds _______________
5. Alarm delay, exhaust air fan 30 seconds _______________
6. Alarm output active Mo-Su 00:00 - 24:00 _______________
7. Stop on exchanger alarm No _______________
Settings
1. Setpoint frost protection 7°C _______________
2. Setpoint shut-down mode 25°C _______________
3. Pump stop. Min outdoor temp, 6°C _______________
start- stop delay 15 minutes _______________
4. Cool-down (electric heating) 120 seconds _______________
5. Delay supply air fan 60 seconds _______________
time with 100% Exch. at start 90 seconds _______________
6. Extended running.Pushbutton 0 minutes _______________
7. P-band Y2,Y3. Factor 0,5 / 0,5 _______________
8. Min outdoor air, mix. damper Y2 0 % _______________
9. Free cooling. Min outdoor temp10°C _______________
difference outdoor/indoor 3 K _______________
10.Free cooling. Setpoint room 21°C _______________
11.Cooling recovery.
Diff outdoor-/exhaust air temp 2 K _______________
12.DX-cooling. Min. on-/off-times 5 min. and 5 min. _______________
13.DX-cooling. Lowered min.lim. 5 K _______________
14.DX-cooling. Min. outdoor temp. 12°C _______________
15.Starttime damper exercising. 00:00 _______________
16.Min-temp and P-band,
liquid conn. exch. 2°C and 5K _______________
17.Force fan low speed
on low outdoor temp Yes / -10 °C _______________
18.SF/EF pressure range 500/500 Pa _______________
19.Damping factor AI1...AI8 1 _/ _/ _/ _/ _/ _/ _/_
20.Function DI1...DI8 + _/ _/ _/ _/ _/ _/ _/_
20.Show Min/Max-temp AI3...AI8 No _______________
Installation
System
Commiss. date Commiss. by
Page 2
