Manual CORRIGO C-SERIES 2000.09
Commissioning protocol
Configuration Factory setting Commissioning setting
Config.code 1 0011.1110.0000 ____._____._____
Config.code 2 0100.010 ____._____
A. CONTROL FUNCT. 0 Supply air control _______________
B. HEATER TYPE 0 Water heater _______________
C. SEQUENCE Y1 1 Heating _______________
D. SEQUENCE Y2 1 Plate-exchanger _______________
E. SEQUENCE Y3 1 Cooling _______________
F. FROST PROTECTION 1 Y1 _______________
G. SHUTDOWN MODE 1 Yes _______________
H. PUMP STOP 0 No _______________
I. EFF MONITORING 0 No _______________
J. DX-COOLING 0 No _______________
K. COOLING RECOVERY 0 No _______________
L. FREE COOLING 0 No _______________
M. FUNCT. DI6/DU6 0 Ext.alarm+frost prot. _______________
N. FIRE ALARM 1 SF+EF Stop _______________
O. FUNCTION DI7/DI8 0 --- _______________
P. 2-SPEED FANS 0 No _______________
Q. EXTERNAL SETPOINT 0 No _______________
R. DAYLIGHT SAVING 1 Yes _______________
S. HUMIDITY CONTROL 0 Humidif/Dehumidification _______________
BASIC SETTING No Used to reset to factory settings
Control Temp
Setpoint / Actual 20.0 _______________
Min.limit / Max.limit 10.0°C / 30.0°C ________ / _____
PBand / Itime / Nz 20K / 60s / 2K _____/_____/____
Room P/I Factor 0.5 / 2.0 _______________
Casc.f / Itime 2.0 / --- _______________
Setp.Room/ Outdoor temp 22.0 / 12.0 _______________
Outdoor comp. point 1 -20°C / 0.0°C _______________
Outdoor comp. point 2 20°C / 0.0°C _______________
Outdoor comp. point 3 25°C / 0.0°C _______________
Outdoor comp. point 4 30°C / 0.0°C _______________
Control Pressure
Setpoint SF/EF 300 / 300Pa ________ / _____
Reduced SF/EF 200 / 200Pa ________ / _____
SF P / I / D 200Pa / 60s / 0.0 _____/_____/____
EF P / I / D 200Pa / 60s / 0.0 _____/_____/____
Outdoor comp. point 1 -20°C / 0Pa _______________
Outdoor comp. point 2 20°C / 0Pa _______________
Outdoor comp. point 3 25°C / 0Pa _______________
Outdoor comp. point 4 30°C / 0Pa _______________
Control Humidity
Setpoint / Actual --- ________/______
Max.limit / Actual 80%RH / --- _______ / ______
PBand / Itime 40%RH / 60s _______/_______
Installation
System
Commiss. date Commiss. by
Page 1
C10 and C20 only
C10 and C30 only
C10 and C20 only
C30 and C40 only
C20 and C40 only
C30 and C40 only
