Regin RCFD-230C User Manual

Display layout
✓ The current user defined setpoint adjustment (SP
adj
)
3.2.5 View mode settings
Parameter Description
44 Inactive delay
Delay for the display to dim down and enter Idle mode. If set to 0 the display never dims down.
45 Display setting for Idle mode
0 = Show the calculated setpoint (SP
calc
)
1 = Show the room temperature
46 Display setting for the Setpoint mode
0 = Show the calculated setpoint (SP
calc
)
1 = Show the user defined setpoint adjustment (SP
adj
)
47 Positive setpoint adjustment. The maximum allowed user defined setpoint adjustment (SP
adj
) increase.
48 Negative setpoint adjustment. The maximum allowed user defiined setpoint adjustment (SP
adj
) decrease.
49 Brightness of segment at Active and Setpoint mode as well as in the parameter list
Modbus register Modbus address Description
Holding register 37 User defined setpoint adjustment (SP
adj
) set by using the arrows
Can be reset remotely.
0 = No current setpoint adjustment made
Holding register 38 Positive user defined setpoint adjustment. The maximum allowed setpoint
adjustment (SP
adj
) increase.
Holding register 39 Negative user defined setpoint adjustment. The maximum allowed setpoint
adjustment (SP
adj
) decrease.
Holding register 53 Display inactive delay
Delay for the display to dim down to Idle mode. If set to 0 the display never
dims down.
Holding register 57
Display setting for Idle mode
0 = Show the calculated setpoint (SP
calc
)
1 = Show the room temperature
Holding register 58 Display setting for the Setpoint mode
0 = Show the calculated setpoint (SP
calc
)
1 = Show the user defined setpoint adjustment (SP
adj
)
Holding register 59 Intensity or "brightness" of display when in Active and Setpoint mode
Holding register 60 Intensity or "brightness" of display when in Idle mode
3.3 Buttons
Symbol Description
Changeover button
This is a combination of two segments, the outer arrows and the inner sun/
snowflake. These two segments are controlled individually.
Arrow up/Increase button
On/Off button
Arrow down/Decrease button
Fan button
RCFD-230C manual, Rev. A 17
