Technical data
A.2.2 Inputs & Outputs
Please refer to the manual Inputs and outputs specifications for detailed information regarding the inputs and
outputs in this model.
Digital outputs, total max.
current (fuse)
Max 2 A continuous load, total max 6.3 A (fuse 6.3 AT 5 x 20 mm)
Power output a (POa) 24 V DC, max. 50 mA
A.2.3 Communication ports
Communication ports 3
Serial ports 2
Ethernet ports 1
A.2.4 Serial ports
Port type RS485
Port number 1 and 2
Default protocol EXOline slave
Supported protocols Modbus slave / EXOline master / EXOline slave / EFX master
Port isolation Yes (port 1), No (port 2)
Communication speed 9600 baud (1200…38400)
Parity Even (odd/even/no parity)
Stop bits 8 bits, 1 or 2 stop bits
Cable connection Push-in connector or screw terminals
A.2.5 Ethernet port
Port type Ethernet
Default protocol EXOline-TCP
Supported protocols EXOline-TCP / BACnet/IP / Modbus TCP/IP
Cable connection RJ45, 10Base-T/100Base-TX auto-negotiation
Cable length Max. 100 m
Cabling Cat 5
A.2.6 Material
Material, housing Polycarbonate, PC
A.3 EXOcompact Vido
A.3.1 General data
Supply voltage 230 V ~ (217…253 V ~ )
Power consumption 10 VA
Protection class IP20, IP40 when mounted in cabinet door
24
EXOcompact Ardo, Eedo and Vido manual, Rev.
B
