Technical data
Ambient humidity Max. 95 % RH, non-condensing
Ambient temperature 0…50 °C
Storage temperature -20…+70 °C
Operating system EXOrealC
Battery backup Memory and real-time clock, at least 5 years
Mounting DIN-rail, cabinet or wall, or over a device box
Number of modules 9
Display Internal or external (accessory)
Dimensions (WxHxD) 147 x 98 x 76 mm
Weight 0.37 kg
A.3.2 Inputs & Outputs
Analogue inputs (AI) PT1000 (-50…+150°C), Ni1000 DIN (-40…105°C), Ni1000 L&G (-40…120°C), Resistance
(800…1600 Ohm)
Digital inputs (DI) Sourcing input type, GND is ref
Analogue outputs (AO) 0…10 V DC (12 bit D/A short-circuit protected)
Digital outputs (DO) Relay output, 230 V AC, max 1 A continuous load, total max 7 A
Universal analogue I/O (UA) AI or AO
A.3.3 Communication ports
Communication ports 3
Serial ports 1
Ethernet ports 1
M-Bus port 1
A.3.4 Serial ports
Port type RS485
Port number 1
Default protocol EXOline slave
Supported protocols Modbus slave / Modbus master / EXOline master / EXOline slave / EFX-master
Port isolation Yes
Communication speed 9600 baud (1200…115 200)
Parity Even (odd/even/no parity)
Stop bits 1 or 2 stop bits, 8 bits
Cable connection Push-in connector or screw terminals
A.3.5 Ethernet port
Port type Ethernet
Default protocol EXOline-TCP
Supported protocols EXOline-TCP / BACnet/IP / Modbus TCP/IP
Cable connection RJ45, 10Base-T/100Base-TX auto-negotiation
EXOcompact Ardo, Eedo and Vido manual, Rev.
B
25
