Alternatively the water recirculation cooling can be installed, available from Reitel.
3.4 Connection for power supply
Left side of the device (24)
Connection for
power supply
Power requirements
device
max. distance
Laboratory installation
Power connection Pre-installed 2,5 m 230V / 16A
50 / 60 Hz socket
Plug the IEC power connector in the device’s plug and connect to the supply network
230V 50 / 60 Hz. Check voltage.
Protection: blowout fuse 16 A slow action line relay K16A or C16A,
minimum tension 215V / max. 240V.
Attention: When using the water cooling unit pls. control the water inlet temperature! Max.
30
0
C, temperature of draining water max. 35
0
C
Using the water cooling unit, outflowing water has to be redirected to the storing basin.The
hose end has to be kept under water. Pls. pay attention to choosing the right taps.
WARNING: Do
not connect any further devices to the 16A fuse.
