REITEL INDURET COMPACT - Appendix; Muffle Overview Chart

34
ve4 E62184 Valve plug for mould’s chamber 1 piece
ve6 E60076 Solenoid valve water inlet 1 piece
ve8.1 E62078.1 Small purple valve 1 piece
vh0.1 E62010.1 Sealing lever incl. star knob 1 piece
vi1 E70181 Injector for producing vacuum 1 piece
vs1.1 E62141.1 Safety valve 1 piece
vs3 E62183 Socket joint for thermocouple 1 set
vt6 E71546 Valve for pistle lever 1 piece
zp5 E71545 Cylinder pneumatics 1 piece
zu0 E70850 Grey feed 1 piece
12 Appendix
[Appendix A1] Muffle Overview Chart
The Induction Casting Machine is suited for the following muffles:
Nr. Diameter
[mm]
Steel cylinder Length
[mm]
Weight +-10%
[g]
1
3
6
9
12
30
48
65
80
95
yes
yes
yes
yes
no
55
55
55
55
75
75
200
400
600
950
Other muffle systems have to be adjusted by modification of the shims, in order to grant a
100 % chamber density.
